Diameter 300mm Power Transformer Cooling Fan Sickle Impeller Fan

FOB Reference Price:Get Latest Price
1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Axial Flow Fan
Electric Current Type:
AC
Mounting:
Wall Fan
Blade Material:
Stainless Steel
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Jasonfan
Model Number:
FJ4E-300.FG
Voltage:
230V
Power:
50/60Hz
Air Volume:
1080-1160CFM
Speed:
1350-1450RPM
Certification:
CE, ROHS
Safety:
Thermally protected
Operation System:
Dual high precise ball bearing
Dielectric Withstand Voltage:
AC 1800V at 0.5mA 50/60Hz
Allowable Ambient Temperature Range:
-30~+75 degree
Power Supply Connection:
Wire or terminal box set
Insulation:
F Class
Protection Grade:
IP44
Unit weight:
3.0kg
After-sales Service Provided:
No overseas service provided
Supply Ability
Supply Ability:
300000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
standard carton
Port
Ningbo/Shanghai
Lead Time :
10days after deposit

 Jasonfan series of external rotor fans are space-save classical products which can realize the exchange of hot and cool air flow in various kinds of devices. The advantage of lowest noise and superior efficiency will be your best choice. Our fans are especially suitable to be applied for ventilation, clean room technology, air conditioner, cooling industries etc.

Product Images



Product Description



Overview

  • Allowable environment temperature and humidity range: (under unconcretionary condition)

       -30°C ~+75°C (temperature) 0% ~95% (humidity)

  • Dielectric withstanding voltage: AC 1800V,1 min at 0.5mA, 50/60HZ
  • Insultaion Isolation Grade: F      Protection Grade: IP 44
  • Unit Weight: 3.0Kg

Material

  • Fixed guard: Steel wire is finished with black oven backed painting and anti-corrosion treatment.
  • Impeller: pressed from metal armor plate, impellers are installed on rotor by press. surface is finished by black paint and anti-corrosion treatment.
  • Bearing Type: Maintain-free NSK ball bearing.
  • Power Supply Connection: Wire connection or terminal box set.

Specifications

Category

Axial fan

TypeFJ4E-300.FG
Rated Voltage

230V

Frequency

50/60Hz

Current

0.33A-0.35A

Input Power

69W-77W

Speed

1350RPM-1450RPM

Max Air Flow

1080-1160CFM

StaticPressure

60Pa-90Pa

Noise

57dB-60dB

Capacitor

2.0/450

Weight

3.0KG

Dimensions



• Rotation direction of blades : CCW seen from the front impellers

• Power Connection: Lead or terminal box

• Unit weight: 3.0kg



Product Application



Certifications

       WE  ARE  LEADING  PROFESSIONAL  MANUFACTURER

Our Main Market: Domestic Market(45.00%), North America(15.00%), Oceania(10.00%), Africa(3.00%)

Southeast Asia(10.00%), Western Europe(7.00%),  Mid East(6.00%), South America(4.00%)



Cooperation Brands



Note

All the listed price is only for references, for the latest price please contact us directly.



CLICK HERE TO EMAIL ME: Shirley Lv



Company Information

About us

   We are specialized in developing and producing

axial fans, centrifugal fans and air filters in different

sizes with high quality in the cooling and ventilation

fields. All of our products are reliable and they can

work in harsh circumstance efficiently. They are

featured in High airflow, Low noise and Durable life.

Our company reposes on a simple Chinese

city - Yueqing, which is famous for low-voltage

electronics and precision industry around the world.

   Devoted to the development of fans and insisting

on high quality are the spirit and the principle of our

company. We will try our best to satisfy the most

rigorous inquiries of customers and make Jasonfan

a worldwide welcomed brand.

Workshops



For assuring the stability and consistency of product quality, we try our best to increase the self-making rate of all the parts. We have attained more than 90% self-making rate until now, from the raw material purchase to injection and die-casting. In our plant, we cacarry our production and stock process strictly according to Iso9001 standar. All the steps including receiving material, production, inspection, stock and Ex-warehouse, we carry out through our ERP system. During production, semi-finished products must get through three inspections--withstanding voltage testing, earth testing and conventional testing. Every product has a unique laser-printed code for quality trace.

Testing Equipments



Skill achieves excellence. We set up a Professional laboratory system, including test equipment for air flow, noise and high-low temperature alternating cabinet (salt spray chamber included), etc. Our technician team members achieve their ideas of air movement solution through circuit analysis, test of reliability and environment in this laboratory system. As response to the new rule of EU ERP regulations, we have accomplished the efficiency test of every model we have.



Packaging



It is very important to protect our fans during their transportation to our customers. We replaced our foam packing with carton paperboard as interval of fans in order to avoid environmental problem of foam. We load all the cartons on pallet in order to save labor force cost for our customer. And we also supply plastic film parcel up the outside of the pallet for waterproof if our customers’ end are in rain reason.
